Specifications:
• Frame make: Galvanized steel, Stainless steel, Aluminum
• Media: Elastic Glass Fiber
• For a better dust absorption and containment the media is coated with a hygienic acceptable dust binding agent.
Type:
- SAF G3 Panel
Form of Delivery:
- Glass fiber panel filter with metal frame
Reusable:
- No
Technical Data
Type | SAF G3 Panel |
Class EN 779 | G3 |
Efficiency acc. to EN 779[%] | 82 |
Nominal air flow rate [m^3/h*m^2 ] | 5400-7200 |
Initial- ∆P at nominal flow rate[Pa] | 1.5-2 |
Recommended final pressure difference in[Pa] | 50 |
Max. temp. [°C] | 140 |
Initial- ∆P at nominal flow rate[Pa] | 45 |
